Draper Platforms
BP15 Belt Pickup Platform
- Pick up 30 acres of wheat and 23 acres of canola windrows per hour with an X9 Combine and BP15*
- Increase feed auger speed by 20% for canola and high-yielding wheat**
- Appropriately set larger 20” gauge wheels without tools to match changing conditions
- Save up to 0.10 bushels of canola per acre with a factory installed Crop Shield***
Specs & Compare
Add Model
Specs & Compare | ||||
---|---|---|---|---|
Select up to 4 models to compare specifications | John Deere BP15 Belt Pickup Platform |
Key Specs
Total picking width | 4.55 m 14.9 ft |
|||
---|---|---|---|---|
Header height control | Electrohydraulic | |||
Number of fingers per belt | 84 center belts 77 outer belts |
|||
Auger diameter | 66 cm 26 in. |
|||
Auger fingers | Heavy-duty and round with breakaway notch Diameter: 15.9 mm 0.625 in. |
Header
Transport widths | 5.35 m 17.5 ft |
|||
---|---|---|---|---|
Header height control | Electrohydraulic |
Pickup Belts
Width of belts | 1.13 m 3.7 ft |
|||
---|---|---|---|---|
Number of belts per pickup | Four picking, four transfer | |||
Total picking width | 4.55 m 14.9 ft |
|||
Operating speed of belts | 3-150 m/min 10-475 fpm |
|||
Number of rollers | Two picking, two transfer |
Pickup Fingers
Type | Plastic | |||
---|---|---|---|---|
Number of fingers per belt | 84 center belts 77 outer belts |
Auger
Float range | 57 mm 2.25 in. |
|||
---|---|---|---|---|
Diameter | 66 cm 26 in. |
|||
Auger fingers | Heavy-duty and round with breakaway notch Diameter: 15.9 mm 0.625 in. |
|||
Number of auger fingers | 19 STS, maximum 22 | |||
Auger finger pattern | In-line, retracting | |||
Finger reach | 152 mm 6 in. |
|||
Operating speed | At 520 feederhouse speed: 15t: 180 rpm 18t: 216 rpm |
Tires
Adjustment | Toolless | |||
---|---|---|---|---|
Pressure | 1 bar 103.4 kPa 15 psi |
Crop deflector
Crop deflector | Factory installed |
---|
Weight
Approximate shipping weight (includes shipping skids) | 1647 kg 3630 lb |
---|
Additional information
Date collected | 15 June 2020 |
---|
